Dados Técnicos
Versão Base
| Modelo | i.DC 16 | i.DC 23 | i.DC 34 | i.DC 52 | i.DC 67 | i.DC 84 | i.DC 115 | i.DC 140 | i.DC 175 | i.DC 225 | i.DC 275 | i.DC 330 | i.DC 395 | i.DC 450 | i.DC 610 | i.DC 870 | i.DC 1190 | i.DC 1555 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Caudal (m3/min) | 1,60 | 2,30 | 3,40 | 5,20 | 6,70 | 8,40 | 11,50 | 14 | 17,50 | 22,50 | 27,50 | 33 | 39,50 | 45 | 61 | 87 | 119 | 155,5 |
| PDP (°C) | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 | -40 |
| Pressão (bar) | 5 – 16 | 5 – 16 | 5 – 16 | 5 – 16 | 5 – 16 | 5 – 16 | 5 – 16 | 5 – 16 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 | 5 – 11 |
| Temperatura ambiente(°C) | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 | +2 – +45 |
| Temperatura de entrada de ar comprimido(°C) | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 | +2 – +50 |
| Dimensões L x P x A (mm) | 750 x 750 x 1950 | 750 x 750 x 1950 | 1150 x 750 x 1970 | 1150 x 750 x 1980 | 1150 x 750 x 1980 | 1150 x 750 x 1990 | 1150 x 750 x 1990 | 1150 x 750 x 2000 | 1500 x 1320 x 1910 | 1500 x 1420 x 1930 | 1500 x 1470 x 2090 | 1500 x 1520 x 2125 | 1500 x 1720 x 2146 | 1700 x 1770 x 2225 | 1950 x 1920 x 2258 | 2400 x 2140 x 2456 | 2690 x 2335 x 2701 | 2820 x 2504 x 2536 |
| Peso (kg) | 181 | 220 | 308 | 398 | 421 | 531 | 650 | 815 | 965 | 1275 | 1525 | 1710 | 2080 | 2305 | 2755 | 4105 | 6200 | 6800 |
| Ligação de ar comprimido/ar de regeneração | G ¾” | G ¾” | G 1½” | G 1½” | G 1½” | G 2” | G 2” | G 2” | DN 80 | DN 80 | DN 80 | DN 80 | DN 100 | DN 100 | DN 150 | DN 150 | DN 200 | DN 200 |
| Alimentação elétrica | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz | 100-240 V ± 10% / 1 Ph / 50-60 Hz |
